ECS 1323 Electronical Commutation Slotless DC Motor

Application : Electrical tools,Medical
Model : ECS 1323
Voltage (V) : 6.0V
Speed (rpm) : 28850rpm
Electric : 1.34A
Rated torque : 2.23mN.m

Inquire Now

wzp@wanzhida.cn

We can easily change the shaft,flange structure and connectors to meet different applocation needs.If you are further adjusting the output components,bearings,and windings,you can contact our sales engineers and we will provide you with a customized solution.

Product Mix

Product parameters

Product application

File download

Popular for micromotors

ECS 1323 Electronical Commutation Slotless DC Motor-wanzhida motor

Product application

Electrical tools

With the development of motor and electronic technology, DC motors have been widely used in lawn mowers, electric drills, electric saws, lawn mowers, and electric wrenches below 36V.

Medical

Motor drives are used in numerous medical applications. The motor operates reliably and has the best quality in high-precision equipment such as active implants, insulin pumps, surgical robots, electric tools, ventilators, ventilators, and prostheses.
